Insight Series P4i
Product information
Description
Product specifications
Design
- In-Wall
- In-Ceiling
Planar Magnetic
- Highly Detailed & Dynamic
- (1) Planar Magnetic Driver
- Covers 5 Octaves of Clarity
- Light Weight Film PEEK
- FAST Acceleration
Flexibility
- Can be Mounted Vertically or Horizontally
- Custom Length Grilles Available
Additional
- Full Range Loudspeaker
- (4) High Operating Woofers
- 1-CH’s of Amplification Required
Frequency Response (Using Minimum Air Volume Spec) : 80Hz – 20kHz
Impedance : 6 ohms
Sensitivity : 86 dB / 2.83 V / 1m
Crossover Frequency : 650 Hz
Dispersion (Horizontal x Vertical, -6dB) : 60° x 30°
Max SPL (1 Meter) : 109 dB
Shipping Weight : 23 lbs. (11kg)
Dimensions HxWxD : 31.61” x 5.52” x 3.43” (79.9cm x 13.7cm x 8.7cm)
Product Description
The Insight Series P4i is part of the Wisdom Audio Insight Series, distributed in the UAE and across the GCC by Cache Robotics under exclusive distribution rights.
The P4i as L/C/R in mid-size cinema
For a 25 to 45 m² cinema (typical Dubai villa cinema room size), the P4i is the most-specified Insight Series L/C/R. It delivers the full planar magnetic acoustic signature in a cabinet sized for the room. Larger cinema rooms move up to the P6i or L8i; smaller rooms work well with the P2i.
System building with the P4i
Three P4i across the front, four P2i for surrounds, and four to six Insight ICi6 overhead is the textbook 7.1.4 Atmos build for a UAE luxury villa cinema. Cache Robotics provides UAE-based pre-sales engineering and demo unit access at the Al Quoz showroom for projects specifying full Insight Series systems.
Wisdom Audio Insight Series
The Wisdom Audio Insight Series is built around proprietary planar magnetic thin-film driver technology. Where conventional speakers use cone drivers and dome tweeters split across a crossover, planar magnetic drivers distribute sound across a wide flat surface as a single acoustic source over most of the audible range. The result is unusually coherent tonal reproduction, minimal phase distortion, and directional precision that couples well with the room. Cache Robotics is the official GCC-exclusive distributor for Wisdom Audio, covering the UAE, Saudi Arabia, Kuwait, Qatar, Bahrain, and Oman.
How this fits in the Wisdom Audio Insight Series
Cache is the official GCC-exclusive distributor for Wisdom Audio. The Insight Series is project-quoted on enquiry.
| Model | Format |
|---|---|
| Insight P2i | Compact in-wall, surround channels in compact cinema |
| Insight P4i | In-wall, mid-size cinema L/C/R or surround |
| Insight P6i | In-wall, reference L/C/R for large cinema |
| Insight L8i | In-wall flagship line-source for highest output |
| Insight P2m | On-wall, alternative to P2i where in-wall is not feasible |
| Insight P4m | On-wall, alternative to P4i |
| Insight ICi6 | In-ceiling, Atmos overhead and ceiling-mount LCR |
| Insight P7M-LCR Soundbar | Reference soundbar for displays without separate L/C/R |
Browse the full Wisdom Audio Insight Series on Cache.
Wisdom Audio Insight Series products are project-quoted on enquiry. Cache Robotics is the official GCC-exclusive distributor, covering the UAE, Saudi Arabia, Kuwait, Qatar, Bahrain, and Oman.
Pricing and availability in the UAE
Cache Robotics is the official UAE distributor for this product. Verified UAE AV integrators can request trade pricing, project quotes, and demo access. Full datasheet and current stock status on request. WhatsApp +971 58 541 2806 with your project brief for a same-day response.
